SMT patch processing car vehicle power module control board custom PCBA assembly circuit board IATF16949

Send Inquiry

Request To Call Back

SMT patch processing car vehicle power module control board custom PCBA assembly circuit board IATF16949

Name: SMT patch processing car vehicle power module control board custom PCBA assembly circuit board IATF16949
Brand: Shenzhen Dasonghe Trading Co., Ltd.

Get a Price/Quote

MOQ : 100 Pieces

SMT patch processing car vehicle power module control board custom PCBA assembly circuit board IATF16949 Specification

Processor Speed
Optional microcontroller, up to 48 MHz

Thermal Conductivity
1.0 W/mK (PCB material)

Input
12V DC input from vehicle power

Charging Voltage
12V/24V DC input

Features
Custom SMT assembly, high efficiency, automotive-grade, IATF16949 certified

Power Supply
Automotive battery

Output
Regulated voltage output to subsystems

IP Rating
IP20 (PCB level, enclosure dependent)

Interface
Terminal blocks, automotive connectors

Usage
Automotive electronic systems

Sensors Specification
Compatible with common automotive voltage/current sensors

Operating Temperature
-40C to +85C

Power Source
Vehicle battery

Components
SMT passive and active components, capacitors, resistors, IC controllers, MOSFETs, connectors

Response Time
<10 ms switching

Product Type
Custom PCBA assembly

Application
Car vehicle power module, automotive electronic control systems

Rated Voltage
12V DC

Supply Voltage
12V - 24V DC

Size
Customized

Dimension (L*W*H)
120 mm x 80 mm x 12 mm

Function
Vehicle power module control, power management, signal processing

Color
Green PCB with white silkscreen

Weight
Approx. 85 g

Thickness
1.6 mm (PCB thickness)

Current Rating
10A max

Capacity
Supports up to 10 Amps current

Frequency
DC operation

Assembly Type
SMT patch processing, lead-free soldering

PCB Material
FR4, halogen free, RoHS compliant

Surface Finish
HASL or ENIG (optional)

Layer Count
2-6 layers (customizable)

Testing
100% functional and aging test

Mounting Method
Through-hole and surface mount

SMT patch processing car vehicle power module control board custom PCBA assembly circuit board IATF16949 Trade Information

Minimum Order Quantity
100 Pieces

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

About SMT patch processing car vehicle power module control board custom PCBA assembly circuit board IATF16949

Experience the ultimate deal with our SMT patch processing car vehicle power module control board-custom PCBA assembly circuit board IATF16949 certified for enviable automotive performance. Redeem cost-effective, noble engineering with options like lead-free soldering, HASL or ENIG surface finish, and customizable layer counts from 2-6 layers. Crafted from FR4, halogen-free, and RoHS-compliant material, our PCBA supports up to 10A at 12-24V DC with a fast, <10 ms switching response. Every board undergoes 100% functional and aging tests for outstanding reliability in automotive electronic systems.

Versatile Applications Across Automotive and Beyond

Designed primarily for car vehicle power module control, this custom PCBA assembly is perfect for automotive electronic control systems. Its adaptable design also finds use in electric vehicles, power management projects, and smart automotive subsystems. With compatibility for common voltage and current sensors, this module excels in both commercial automotive fleets and specialty vehicles-making it ideal for any application requiring precise power delivery and signal processing in demanding environments.

Efficient Domestic Logistics and Secure Shipment

Our shipped goods travel through leading FOB ports in China, ensuring timely delivery with efficient logistics. Each power module circuit board is securely packaged to safeguard against transit expenditure and environmental risks. Available across the main domestic market and global regions, our robust packaging preserves both quality and function, guaranteeing the units reach you ready for integration into your automotive or industrial applications without compromise.

FAQ's of SMT patch processing car vehicle power module control board custom PCBA assembly circuit board IATF16949:

Q: How is the SMT patch processing board assembled?

A: The board uses advanced SMT (Surface Mount Technology) processing, featuring both through-hole and surface mount components, placed and soldered using lead-free methods for environmental compliance.

Q: What are the key benefits of this PCBA circuit board for automotive use?

A: It delivers a cost-effective, reliable power management solution, with rapid response times (<10 ms), compatibility with standard automotive sensors, and robust operation from -40C to +85C.

Q: Where can this vehicle power module control board be applied?

A: This PCBA is suited for car power modules, automotive control systems, electric vehicles, power management units, and industrial control applications that require regulated voltage and reliable switching.

Q: What is the testing process for quality assurance?

A: Each unit undergoes 100% functional and aging tests, ensuring all boards meet IATF16949 automotive standards and deliver consistent performance under real-world conditions.

Q: How can I redeem an order and what shipping options are available?

A: Orders can be placed through our dealer or distributor channels. Shipped goods are dispatched via major Chinese FOB ports, with logistics tailored to your requirements and secure packaging included.
