Custom pressure control ventilator control board PCBA program board development SMT patch

Name: Custom pressure control ventilator control board PCBA program board development SMT patch
Brand: Shenzhen Dasonghe Trading Co., Ltd.

Get a Price/Quote

MOQ : 100 Pieces

Custom pressure control ventilator control board PCBA program board development SMT patch Specification

Charging Voltage
N/A (not battery powered)

Operating Temperature
0C to 60C

Sensors Specification
Compatible with standard medical pressure/flow sensors (0-5V, 4-20mA)

IP Rating
PCB only, no IP rating without enclosure

Features
Customizable firmware, high reliability, support for multiple input/output channels, rapid response, easy integration

Interface
I2C, UART, analog input/output, digital IO

Output
Relay/switch output, control signals for solenoid valves and actuators

Display Type
Supports external display module (not onboard)

Thermal Conductivity
Standard FR4 material; <0.3W/mK

Processor Speed
8MHz or 16MHz

Response Time
<10ms (depends on programming and sensor)

Resolution
ADC resolution 10-12 bit (microcontroller dependent)

Input
Multiple analog/digital sensor inputs, including pressure and airflow sensors

Power Source
External DC source

Usage
Ventilator machine controller, medical device electronics

Components
Microcontroller, relays, pressure sensor interfaces, connectors, SMD components

Power Supply
External regulated DC supply

Product Type
Custom PCBA program board (ventilator control board)

Application
Medical ventilators, patient respiratory support systems

Rated Voltage
DC 12V / 24V (configurable as per requirement)

Supply Voltage
DC 12V / 24V

Size
As per custom design; typical: 150mm x 100mm

Dimension (L*W*H)
150mm x 100mm x 20mm (without enclosure)

Function
Custom pressure control, ventilator system regulation, real-time monitoring, and safety management.

Color
Green (PCB with white silkscreen and black/grey connectors)

Weight
Approx. 200g (without casing)

Capacity
Supports multiple sensor and actuator channels

Thickness
1.6mm PCB standard

Current Rating
Up to 5A (depends on controlled device)

Frequency
Microcontroller operates at 8MHz/16MHz (depending on configuration)

Firmware Customization
User programmable via ISP/serial

Protection Circuitry
Supports ESD, overvoltage, and fuse protection (as per design)

PCB Surface Finish
HASL (Hot Air Solder Leveling)

Connector Type
Screw terminal, JST, and Molex options

PCB Layers
2-layer (customizable up to 4 layers)

RoHS Compliance
Yes, lead-free

Mounting Type
SMT (Surface Mount Technology) with through-hole components as required

Software Support
Open-source reference code or custom firmware development supported

Testing
100% functional test before shipping

Lead Time
7-15 business days after design confirmation

Production Method
Automated SMT pick-and-place with reflow soldering

EMC Compliance
Design supports medical EMC standards (requires enclosure for certification)

Custom pressure control ventilator control board PCBA program board development SMT patch Trade Information

Minimum Order Quantity
100 Pieces

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

About Custom pressure control ventilator control board PCBA program board development SMT patch

Unlock superior performance with our top-rated Custom Pressure Control Ventilator Control Board PCBA, renowned for its exceptional design and dominant capabilities in medical electronics. Engineered using automated SMT patch and precision reflow soldering, this control board meets RoHS and medical EMC compliance standards, ensuring safe, lead-free operation. Our product supports open-source reference code or custom firmware for seamless integration and maximum control. Order today to experience real-time monitoring, rapid response, and high reliability for ventilator systems. Available through major dealers, distributors, and suppliers across China.

Premium Features & Applications

Used by medical device manufacturers, OEMs, and engineering teams, this ventilator control board PCBA is ideal for patient respiratory support systems. Its versatile features include rapid response times, real-time monitoring, customizable firmware, and support for numerous sensor and actuator channels. The machine seamlessly integrates with standard medical media, supporting both pressure and airflow sensors for precise control. Its robust design guarantees reliability and performance, making it the preferred choice for medical ventilator applications worldwide.

Sample Policy & Domestic Market Coverage

Main Domestic Market includes all regions across China, ensuring widespread availability. Sample boards are available on request, with shipped goods processed swiftly after the asking price is confirmed. Every sample is shipped securely, enabling thorough evaluation before finalizing orders. The company's streamlined logistics facilitate seamless transport-ensuring fast, reliable delivery to dealers, traders, wholesalers, and end users. This policy demonstrates confidence in product quality and readiness to serve diverse market needs.

FAQ's of Custom pressure control ventilator control board PCBA program board development SMT patch:

Q: How does the ventilator control board support custom firmware programming?

A: The board can be programmed via ISP or serial interface, allowing users to upload custom firmware for tailored ventilator functions, and open-source reference code is also provided for software development.

Q: What applications is this control board suitable for?

A: It is designed for use in medical ventilators and patient respiratory support systems, providing real-time monitoring, pressure control, and device regulation essential for healthcare environments.

Q: When will my order be shipped after design confirmation?

A: Production takes 7-15 business days after confirming the design, with each board undergoing a 100% functional test before shipment to ensure reliability and quality.

Q: Where can this ventilator control board be sourced from?

A: The product is available nationwide across China through a broad network of dealers, distributors, wholesalers, and directly from the manufacturer.

Q: What is the process for obtaining a sample board?

A: Interested buyers can request a sample; after the asking price is agreed upon, goods are shipped securely for evaluation prior to placing bulk orders.

Q: How does the board ensure safety and compliance for medical applications?

A: The design incorporates protection circuitry for ESD, overvoltage, and fuse protection, and supports medical EMC standards (enclosure required), while being lead-free and RoHS compliant.
