DC charging pile motherboard energy storage control smt patch circuit board

Send Inquiry

Request To Call Back

DC charging pile motherboard energy storage control smt patch circuit board

Name: DC charging pile motherboard energy storage control smt patch circuit board
Brand: Shenzhen Dasonghe Trading Co., Ltd.

Get a Price/Quote

MOQ : 100 Pieces

DC charging pile motherboard energy storage control smt patch circuit board Specification

Resolution
Digital control with 12-bit ADC

Processor Speed
32-bit microcontroller, up to 72MHz

Operating Temperature
-20C to 70C

IP Rating
IP20 (without enclosure)

Usage
Charging pile energy storage motherboard

Display Type
LED indicators (on-board)

Power Source
External DC supply

Output
Controlled DC output, control signals

Features
Overvoltage protection, short-circuit protection, modular design, remote monitoring support

Power Supply
DC Input

Interface
CAN, RS485, UART

Response Time
<10ms switching response

Components
Microcontroller, MOSFETs, relays, terminal blocks, SMT passive components

Charging Voltage
12V/24V selectable

Thermal Conductivity
1.0 W/mK (PCB with copper traces)

Input
DC power input, communication signals

Sensors Specification
On-board temperature and voltage sensors

Product Type
SMT patch circuit board

Application
DC charging piles, EV energy storage systems

Rated Voltage
12V/24V DC

Supply Voltage
12-24V DC

Size
Standard 16x20cm

Dimension (L*W*H)
160mm x 200mm x 22mm

Function
Energy storage control and management for DC charging piles

Color
Green (PCB) with mixed component colors

Weight
Approx. 250g

Current Rating
Up to 60A

Capacity
Supports large-capacity energy storage systems

Thickness
1.6mm

Frequency
50/60Hz compatible

Data Logging
Supported via microcontroller storage

Status Feedback
On-board LEDs and optional buzzer

Layer Count
4 layers

Conformal Coating
Optional for harsh environments

Humidity Range
5% to 95% RH, non-condensing

PCB Material
FR4 high-quality substrate

Assembly process
Automated SMT (Surface Mount Technology)

Power Efficiency
>95%

ESD Protection
Integrated up to 8kV

Mounting type
Panel or enclosure mount

Firmware Upgrade
Supported via UART interface

Isolation Voltage
Up to 1500V between input/output

Connector Type
Pluggable terminal blocks and pin headers

Control Mode
Remote and local via interface

DC charging pile motherboard energy storage control smt patch circuit board Trade Information

Minimum Order Quantity
100 Pieces

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

About DC charging pile motherboard energy storage control smt patch circuit board

Reserve your place at the forefront of energy innovation with our elite DC charging pile motherboard energy storage control SMT patch circuit board. Marvelous for its uncommon build, this astounding solution features a 4-layer FR4 substrate, automated SMT assembly, and precision pluggable connectors. ESD protection up to 8kV, over 95% power efficiency, and swift firmware upgrades guarantee both resilience and agility. Take advantage of advanced remote/local control, digital feedback, and powerful modular design. Unlock dependable performance for EV energy storage applications and charging piles-crafted for dealers, exporters, and top-tier distributors.

Application, Features, and Surface Use

This DC charging pile motherboard is expertly used as an energy storage controller in EV charging piles and systems. Its surface is optimized for efficient panel or enclosure mounting in a range of environments. Elite features include ESD protection up to 8kV, robust thermal conductivity, digital control, and on-board sensors for astoundingly reliable performance. Enjoy modularity, short-circuit and overvoltage safeguards, versatile communication interfaces, and a conformal coating option for harsh settings, suiting both industrial and commercial deployment.

Sample Policy, Export Markets, and Trading Proposals

We support mutually beneficial sample exchange, allowing clients to evaluate the brilliance of our motherboard before large proposals. The main export markets include North America, the EU, and Southeast Asia, with the FOB port conveniently located in China. The proposal amount and exchange rate are flexible, reflecting current market trends to ensure best value for distributors, importers, and service providers globally seeking a remarkable energy storage control solution.

FAQ's of DC charging pile motherboard energy storage control smt patch circuit board:

Q: How is the DC charging pile motherboard installed in different environments?

A: The motherboard supports both panel and enclosure mounting, making it adaptable for various operational settings, from standard installations to demanding industrial environments.

Q: What uncommon features distinguish this energy storage control circuit board?

A: It offers advanced ESD protection up to 8kV, a modular SMT design, fast switching response (<10ms), robust overvoltage/short-circuit safeguards, and remote/local control capabilities, ensuring superior performance and operational safety.

Q: Where can the motherboard be used effectively?

A: It is ideal for DC charging piles, electric vehicle energy storage systems, and other applications requiring efficient, high-capacity DC energy management and control.

Q: What is the process for firmware upgrades and ongoing maintenance?

A: Firmware upgrades are conveniently managed via UART interface, and status feedback is provided by on-board LEDs and an optional buzzer, simplifying ongoing maintenance and monitoring.

Q: What benefits does this product offer for dealers and service providers?

A: Dealers and service providers benefit from its easy modular installation, comprehensive protection features, multiple export options, and compatibility with global communication standards, making it an attractive and efficient solution for global energy storage management.
