Monitor motherboard PCBA board SMT patch vacuum reflow welding processing PCB patch double-sided circuit board

Send Inquiry

Request To Call Back

Monitor motherboard PCBA board SMT patch vacuum reflow welding processing PCB patch double-sided circuit board

Name: Monitor motherboard PCBA board SMT patch vacuum reflow welding processing PCB patch double-sided circuit board
Brand: Shenzhen Dasonghe Trading Co., Ltd.

Get a Price/Quote

MOQ : 100 Pieces

Monitor motherboard PCBA board SMT patch vacuum reflow welding processing PCB patch double-sided circuit board Specification

Input
LVDS, VGA, HDMI, DVI (customizable depending on configuration)

IP Rating
None (not waterproof, for indoor use)

Output
Display signal output to LCD panel

Components
Multi-layer PCB, capacitors, resistors, ICs, connectors, crystal oscillator

Features
SMT patch, vacuum reflow welding, double-sided mounting, high reliability

Resolution
Up to 1920x1080 (Full HD)

Thermal Conductivity
Standard FR-4 PCB material, ambient thermal management required

Processor Speed
Up to 1GHz (depending on onboard controller IC)

Sensors Specification
Optional light sensor/thermal sensor support

Response Time
Typically <20ms (panel dependent)

Power Supply
DC power supply via onboard connector

Operating Temperature
-20C to +70C

Interface
HDMI, VGA, LVDS, DVI, RS232 (custom options)

Usage
SMT patch processing, double-sided component mounting

Charging Voltage
N/A (not battery-powered)

Display Type
Supports TFT-LCD panels

Power Source
External DC adapter

Product Type
Monitor motherboard PCBA board

Application
Industrial, commercial monitors, display equipment

Rated Voltage
12V DC

Supply Voltage
DC 12V

Size
Custom/OEM sizes available, typical 180mm x 110mm

Dimension (L*W*H)
180mm x 110mm x 1.6mm

Function
Monitor motherboard for industrial and commercial display systems

Color
Green (solder mask), with white silkscreen

Weight
Approx. 80g (may vary by configuration)

Capacity
Supports up to Full HD resolution

Thickness
1.6mm

Current Rating
2A max recommended

Frequency
50-60Hz input frequency (for compatible applications)

ESD Protection
Onboard ESD protection circuits for signal lines

RoHS Compliance
Yes

Quality Standard
IPC-A-610 Class 2

Surface Finish
Lead-free HASL (RoHS compliant)

Connector Type
FPC/FFC, HDMI, VGA, power connectors

Tested
Functionally tested and AOI inspected

Storage Temperature
-40C to +85C

PCB Layer Count
4-Layer (customizable options available)

PCB Copper Thickness
1 oz/ft2

Mounting Type
Surface-mount (SMT) and through-hole mix

Moisture Sensitivity Level
MSL 2A

Board Material
FR-4 epoxy glass

Monitor motherboard PCBA board SMT patch vacuum reflow welding processing PCB patch double-sided circuit board Trade Information

Minimum Order Quantity
100 Pieces

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

About Monitor motherboard PCBA board SMT patch vacuum reflow welding processing PCB patch double-sided circuit board

Unlock the premier capabilities of your monitor systems with our Heroic Monitor Motherboard PCBA Board SMT patch-engineered for industrial and commercial demands. Featuring a customizable 4-layer FR-4 epoxy glass PCB, this enlightened product supports SMT and through-hole assembly, Vacuum Reflow Welding and double-sided component mounting. Take advantage of onboard ESD protection, RoHS-compliant lead-free HASL surface finish, and versatile input/output connectors like HDMI, VGA, and LVDS. Every board is functionally tested, AOI-inspected, and meets IPC-A-610 Class 2 standards, ensuring top reliability. Purchase the ideal solution for robust display equipment today!

Industry Advantage and Versatile Application

Take advantage of our advanced Monitor Motherboard PCBA Board, expertly processed with SMT patch and vacuum reflow welding technologies. Its double-sided circuit board design ensures powerful performance for industrial and commercial display systems, including monitors and various LCD equipment. Adaptable for Full HD resolution, this board is the perfect choice for OEM solutions and custom panel interfaces, making it a premier option for manufacturers aiming for reliability and efficiency in display signal management.

Payment Terms, Certifications, and Export Focus

Purchase with confidence-our board is covered by verified certifications such as RoHS compliance and IPC-A-610 Class 2. Flexible payment terms are available to accommodate global clients, with express shipping ensuring prompt dispatching and delivery of shipped goods worldwide. We export primarily to major industrial markets in Asia, Europe, and North America, positioning ourselves as a trusted supplier for heroically engineered monitor motherboard solutions. Experience seamless transactions and reliable international support.

FAQ's of Monitor motherboard PCBA board SMT patch vacuum reflow welding processing PCB patch double-sided circuit board:

Q: How is the PCB tested for quality and reliability?

A: Each board undergoes functional testing and AOI inspection, aligning with IPC-A-610 Class 2 quality standards to ensure reliable performance and high durability in demanding environments.

Q: What applications can this monitor motherboard PCBA board be used for?

A: This board is designed for industrial and commercial monitors, supporting a wide variety of display equipment such as information kiosks, signage, and custom OEM LCD solutions.

Q: When can I expect my order to be shipped after purchase?

A: Orders are typically processed with express shipping options, ensuring prompt dispatching and reliable delivery of your shipped goods to major export markets worldwide.

Q: Where does this product excel compared to traditional single-sided PCBs?

A: The double-sided, 4-layer board configuration allows for greater component density, robust signal integrity, and higher efficiency-making it ideal for advanced, high-resolution display and monitor systems.

Q: What is the process for customizing the PCB configuration?

A: Custom orders are available and begin with a consultation to confirm layer count, interface requirements, and size. Our technical team then develops the PCB to your precise specifications.

Q: How does the onboard ESD protection benefit my equipment?

A: Onboard ESD protection circuits safeguard sensitive signal lines from electrostatic discharges, thus enhancing equipment longevity and reducing the risk of failure in industrial or commercial settings.
