Monitor motherboard PCBA board SMT patch vacuum reflow welding processing PCB patch

Send Inquiry

Request To Call Back

Monitor motherboard PCBA board SMT patch vacuum reflow welding processing PCB patch

Name: Monitor motherboard PCBA board SMT patch vacuum reflow welding processing PCB patch
Brand: Shenzhen Dasonghe Trading Co., Ltd.

Get a Price/Quote

MOQ : 100 Pieces

Monitor motherboard PCBA board SMT patch vacuum reflow welding processing PCB patch Specification

Sensors Specification
Optional ambient light sensor/signal detection as per assembly

Usage
Monitor display module PCB assembly

Power Supply
External DC source/Mainboard connection

Features
High precision SMT patch, vacuum reflow soldering, RoHS compliant

IP Rating
Not rated (for indoor use)

Interface
HDMI, VGA, LVDS, Connector Pads

Thermal Conductivity
Standard FR4, typical range 0.3-0.4 W/mK

Operating Temperature
-10C to 60C

Processor Speed
1GHz (if controller IC present)

Display Type
Supports LCD/LED panels

Power Source
DC input from adapter/mainboard

Components
Resistors, capacitors, ICs, connectors, SMD and through-hole devices

Input
Signal (HDMI/VGA/DisplayPort as per design)

Output
Processed display signal, Power output for display modules

Resolution
Up to 1920x1080 (Full HD), design-specific

Response Time
Typical <10ms (dependent on application/IC)

Product Type
PCBA (Printed Circuit Board Assembly)

Application
Used in LCD/LED monitor assemblies

Rated Voltage
12V DC

Supply Voltage
5V/12V DC (as per design)

Size
120mm x 85mm approx. (customizable)

Dimension (L*W*H)
120 x 85 x 20 mm (approximate, customizable)

Function
Monitor motherboard PCBA board for signal processing and display control

Color
Green (PCB base)

Weight
Approx. 50g (dependent on design)

Current Rating
Max 2A (varies with design)

Capacity
Varies by design/specification

Thickness
1.6mm standard PCB

Frequency
50/60 Hz signal processing capability

Minimum Trace Width/Spacing
0.1mm / 0.1mm

Manufacturing Tolerance
0.1mm (standard electronic PCB)

Mounting Type
Surface Mount (SMT), Through-Hole (as per design)

Customisation
Supported for size, layout, and component selection

Soldering Process
Automated SMT with vacuum reflow welding

ESD Protection
Integrated (on select components/pads)

Conformal Coating
Optional for moisture and dust protection

Product Lifespan
5-7 years typically

Test Method
AOI, X-ray inspection, Functional test

PCB Material
High-quality FR4 epoxy glass

Surface Finish
Leadfree HASL (Hot Air Solder Leveling)

Storage Temperature
-20C to 85C

Layer Count
2-4 layers (customizable)

RoHS Compliance
Yes

Monitor motherboard PCBA board SMT patch vacuum reflow welding processing PCB patch Trade Information

Minimum Order Quantity
100 Pieces

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

About Monitor motherboard PCBA board SMT patch vacuum reflow welding processing PCB patch

Experience the finest in PCB innovation with our best-seller Monitor Motherboard PCBA Board, meticulously crafted using high-quality FR4 epoxy glass. This champion product supports customizations across 2-4 layers and features soaring standards like lead-free HASL finish, 0.1mm trace precision, and advanced vacuum reflow SMT patching. Enjoy rare reliability, with integrated ESD protection, robust functional testing (AOI, X-ray), and compliance with RoHS. Suitable for high-speed signal processing and display control, this hot-deal PCBA delivers superior performance for LCD/LED monitor modules. Secure your order from China's premier supplier and elevate your display solutions.

Versatile Application & Competitive Edge

The Monitor Motherboard PCBA Board with SMT patch and vacuum reflow welding is a top-tier solution for LCD/LED monitor assemblies. Its primary competitive advantages include automated manufacturing, precision soldering, and rigorous AOI plus X-ray testing. Customization for size, layout, and component selection makes it ideal for diverse projects. Suitable for OEMs and display system integrators, it champions signal processing and display control, giving your product an edge in performance and reliability.

Main Domestic Market, Logistics & Delivery

Stock ready in China, this PCBA board can be delivered swiftly via major FOB ports. Packaging is secure, tailored for safe global transit. Our offer includes bulk packaging for manufacturers or special packaging per client's specs. With prompt handling and reliable supply chains, your order is managed efficiently from factory dispatch to your dock, ensuring you always have the inventory in hand when needed for integration or assembly.

FAQ's of Monitor motherboard PCBA board SMT patch vacuum reflow welding processing PCB patch:

Q: How can I customize the Monitor Motherboard PCBA Board for my application?

A: You can customize the board for size, layout, layer count (2-4), and component selection. Let us know your requirements, and our engineering team will support tailored design and production to match your project specifications.

Q: What testing and quality assurance processes are used?

A: Each board undergoes AOI (Automated Optical Inspection), X-ray inspection, and functional testing to ensure performance and reliability. Select models offer ESD protection and optional conformal coating for moisture and dust resistance.

Q: Where is this product suitable for use?

A: This PCBA board is primarily designed for LCD/LED monitor assemblies, but is also suitable for other display modules requiring signal processing and display control with HDMI, VGA, and LVDS interfaces.

Q: What are the primary benefits of vacuum reflow welding and SMT patching?

A: Vacuum reflow welding ensures void-free solder joints, resulting in enhanced electrical connectivity, while SMT patching allows high-precision placement of SMD components-both contributing to superior reliability and performance.

Q: What is the expected lifespan and operating conditions for this PCBA board?

A: With robust design and quality materials, the typical lifespan ranges from 5 to 7 years. It operates reliably within a temperature range of -10C to 60C, with storage conditions from -20C to 85C.
