Charging control module PCBA contractor material SMT patch processing circuit board

Name: Charging control module PCBA contractor material SMT patch processing circuit board
Brand: Shenzhen Dasonghe Trading Co., Ltd.

Get a Price/Quote

MOQ : 100 Pieces

Charging control module PCBA contractor material SMT patch processing circuit board Specification

Power Source
External DC/AC adaptor, solar panel (application specific)

Output
Regulated output for battery/power device charging

Input
DC input (configurable based on application)

Features
Overcharge protection, short-circuit protection, temperature protection, real-time monitoring, SMT patch process

Components
ICs, MOSFETs, connectors, resistors, capacitors, varistors, relays

Sensors Specification
Optional current & voltage sensing, NTC thermistor

Charging Voltage
12V/24V/48V (auto or manual select)

Display Type
Optional LED indicators or digital display

Processor Speed
Depends on microcontroller model, typically 48MHz-120MHz

Thermal Conductivity
Standard FR4, 0.25 W/mK

Operating Temperature
-20C to +70C

Usage
Charging management for battery-powered systems

Response Time
Within 10ms (dependent on load circuit)

Interface
Screw terminals, pin headers,/or JST connectors

Resolution
N/A (not applicable unless with display)

IP Rating
None (open-board module; enclosure recommended)

Power Supply
DC supply or compatible AC-DC adapter

Product Type
Charging Control Module PCBA

Application
Power electronics, electric vehicles, backup batteries, industrial supplies

Rated Voltage
12V/24V/48V (customizable)

Supply Voltage
12V/24V/48V selectable

Size
Custom sizes available; typical: 85mm x 55mm

Dimension (L*W*H)
85mm x 55mm x 18mm (inc. components)

Function
Charging control, monitoring, and protection for power devices

Color
Green (standard PCB solder mask)

Weight
Approx. 18g (varies by configuration)

Capacity
Up to 30A (current handling, model specific)

Current Rating
10A/20A/30A (configurable)

Thickness
1.6 mm (standard PCB thickness)

Frequency
50-60Hz (if AC input supported)

Mounting Type
SMT (Surface Mount Technology), through-hole for some components

PCB Layer
2-layer (standard); multilayer available on request

Storage Temperature
-30C to +85C

Material
High-quality FR4 fiberglass PCB, RoHS compliant solder

ESD Protection
Integrated for sensitive components

Control Method
Microcontroller-based and/or discrete component control

Software Support
Firmware can be customized for advanced functions

MOQ
10 units (sample orders accepted)

Compliance
RoHS and CE (on request)

PCB Finish
HASL or ENIG (optional)

Charging control module PCBA contractor material SMT patch processing circuit board Trade Information

Minimum Order Quantity
100 Pieces

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

About Charging control module PCBA contractor material SMT patch processing circuit board

Introducing the new release Charging Control Module PCBA - an astonishing solution for seamless power management, now available for immediate order. Utilise this unprecedented offer for top-tier SMT patch processing and guarantee stabilised charging, monitoring, and protection across a range of devices. Crafted with ineffable quality-premium FR4 PCB, RoHS compliance, and ESD safety-this module supports custom configurations (12V/24V/48V), multilayer requests, and firmware upgrades. Suitable for electric vehicles, backup batteries, and industrial supplies. Limited MOQ of 10 units-order today and experience excellence from China's leading contractor and supplier.
