Custom solar photovoltaic control board PCBA assembly smt patch processing source scheme board development

Send Inquiry

Request To Call Back

Custom solar photovoltaic control board PCBA assembly smt patch processing source scheme board development

Name: Custom solar photovoltaic control board PCBA assembly smt patch processing source scheme board development
Brand: Shenzhen Dasonghe Trading Co., Ltd.

Get a Price/Quote

MOQ : 10 Pieces

Custom solar photovoltaic control board PCBA assembly smt patch processing source scheme board development Specification

Components
Microcontroller, MOSFETs, relays, protection diodes, connectors, sensor interfaces.

Charging Voltage
PV panel voltage up to 100V max (customizable).

Operating Temperature
-20C to +70C.

Thermal Conductivity
Standard FR4 PCB, 0.25 W/mK.

Sensors Specification
Supports voltage, current, and temperature sensors.

Power Source
Solar PV/battery DC supply.

Interface
RS485, UART, CAN, or custom communication ports (optional).

Usage
Solar power generation system control and monitoring.

IP Rating
Bare board: N/A, housing required for IP65/IP67.

Resolution
Sensor and ADC resolution: 10-12 bit (microcontroller dependent).

Power Supply
DC power from PV panel/battery.

Output
Load output, communication interface output, relay control.

Features
Customizable logic, protections (overvoltage, short circuit, overcurrent, temperature), remote monitoring, real-time data acquisition.

Input
PV panel DC input, sensor and data inputs.

Response Time
<10ms (control response).

Processor Speed
Up to 72MHz (based on microcontroller chosen).

Product Type
Custom PCBA assembled SMT control board.

Application
Solar photovoltaic installations, off-grid solar plants, hybrid energy storage systems.

Rated Voltage
12V/24V/48V (customizable).

Supply Voltage
DC 12V/24V/48V nominal (custom support).

Size
Customizable, e.g., 100mm x 70mm.

Dimension (L*W*H)
As per customization (e.g., 100mm x 70mm x 25mm).

Function
Solar photovoltaic power management, charge/discharge control, system protection, data monitoring.

Color
Green (standard PCB solder mask color).

Weight
Approx. 100g - 250g (depending on configuration).

Thickness
1.6mm typical PCB thickness.

Current Rating
Up to 50A (depending on design).

Capacity
Up to 50A charge/discharge current (customizable).

Frequency
DC application (frequency not directly applicable), optional PWM 10kHz - 40kHz.

Mounting Type
SMT (Surface Mount Technology), through-hole available on request.

RoHS Compliance
Yes

Supported Protocols
Modbus, RS485, CAN (upon request).

PCB Material
High-quality FR4, lead-free compliant.

Quality Standards
ISO9001 production, CE compliant on request.

Conformal Coating
Optional for humidity/dust protection.

Minimum Order Quantity
1 unit (for prototype); higher for mass production.

Customization
Full hardware/software customization available.

Firmware
Upgradeable via serial interface.

Custom solar photovoltaic control board PCBA assembly smt patch processing source scheme board development Trade Information

Minimum Order Quantity
10 Pieces

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

About Custom solar photovoltaic control board PCBA assembly smt patch processing source scheme board development

Highlighted by remarkable versatility and majestic engineering, this custom solar photovoltaic control board PCBA assembly is designed for power management, charge/discharge control, and real-time data monitoring. Redoubtable in quality, it utilizes scarce but high-performance FR4, is RoHS compliant, with a lead-free process, and boasts full hardware/software customization. Grab this board for robust control in off-grid, hybrid, or solar plants-featuring communication protocols (Modbus, RS485, CAN), upgradeable firmware, and protection features. Supported by ISO9001/CE standards, it excels in solar system integration, ensuring reliability in demanding environments.

Application Focus: Site, Usage & Type

Engineered for diverse site installations, this solar photovoltaic control board PCBA assembly is optimized for off-grid solar plants, hybrid energy storage systems, and residential/commercial solar installations. Its specific usage centers around solar power generation system control and real-time monitoring, handling both charge/discharge regulation and vital system protections. Built for flexible usage types-from prototyping to large-scale deployment-this adaptable solution supports integration in both standard and custom solar management projects, ensuring operational excellence where reliability is paramount.

Certifications, Supply & Market Reach

Certified under ISO9001 production with CE compliance available upon request, this product offers peace of mind and markets globally. List prices vary by configuration, and supply is tailored to support both prototyping (from 1 unit) and mass production demands. Prompt dispatching is ensured for domestic and international markets. The main domestic market is China, with a robust supply chain to wholesalers, dealers, service providers, and more, guaranteeing consistent availability and broad distribution coverage.
