Custom solar photovoltaic control board PCBA assembly smt patch

Name: Custom solar photovoltaic control board PCBA assembly smt patch
Brand: Shenzhen Dasonghe Trading Co., Ltd.

Get a Price/Quote

MOQ : 100 Pieces

Custom solar photovoltaic control board PCBA assembly smt patch Specification

Output
DC power output, relay/charging terminals

Operating Temperature
-20C to 70C

IP Rating
Unrated PCB, enclosure dependent

Usage
Solar energy control and monitoring

Charging Voltage
13.8V/27.6V (12/24V systems)

Display Type
LED indicator or LCD (optional)

Sensors Specification
Temperature, voltage, current sensors (optional)

Processor Speed
Microcontroller, 20MHz (example)

Interface
Screw terminals, optional communication port (RS485/UART)

Features
Customizable functions, SMT mount, high reliability, protection circuits

Thermal Conductivity
Standard FR4 material

Response Time
<1ms switching time

Power Supply
Solar panel/DC input

Components
Controllers, MOSFETs, microcontroller, connectors, capacitors, terminal blocks

Power Source
Solar PV or DC adapter

Input
Solar PV input, DC input

Product Type
PCBA assembly, SMT patch

Application
Solar photovoltaic systems, off-grid power units

Rated Voltage
12V/24V (customizable)

Supply Voltage
Max 40V (customizable)

Size
Custom size available

Dimension (L*W*H)
112mm x 80mm x 15mm

Function
Custom photovoltaic power management and regulation

Color
Green (Soldermask)

Weight
Approx. 65g

Capacity
Up to 15A (depends on design)

Current Rating
Up to 15A

Thickness
1.6mm (standard PCB)

Frequency
DC application (no fixed frequency)

Test Method
In-circuit, functional test on request

PCB Material
FR4 (standard)

Mounting Type
Surface Mount (SMT), Through Hole mix-design

Packing
Anti-static bag, ESD safe packaging

Connector Type
Screw terminal, pin header

Manufacturing Process
Automated SMT patch, AOI tested

PCB Layer
2 layer (standard), multi-layer optional

RoHS Compliance
Yes

Customization
Full component and function customization available

Assembly Service
Custom SMT and THT assembly

Protective Features
Overcurrent, short circuit, reverse polarity, over-temperature

Custom solar photovoltaic control board PCBA assembly smt patch Trade Information

Minimum Order Quantity
100 Pieces

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

About Custom solar photovoltaic control board PCBA assembly smt patch

Experience the remarkable performance of our custom solar photovoltaic control board PCBA assembly, highlighted by its advanced SMT patch and full customization options. Manufactured using celebrated FR4 material and robust RoHS-compliant designs, this gorgeous control panel supports 2-layer or multi-layer PCBs, with both surface mount and through-hole capabilities. Equipped with overcurrent, short circuit, and reverse polarity protection, its modular design suits a variety of solar energy control and monitoring systems. Limited stock available during this exclusive promotion-enjoy high reliability, automated assembly, and comprehensive technical support for all your off-grid solar needs. Secure yours now!
