nverted energy storage electronic PCB solution to develop power control BMS circuit board custom SMT patch

Send Inquiry

Request To Call Back

nverted energy storage electronic PCB solution to develop power control BMS circuit board custom SMT patch

Name: nverted energy storage electronic PCB solution to develop power control BMS circuit board custom SMT patch
Brand: Shenzhen Dasonghe Trading Co., Ltd.

Get a Price/Quote

MOQ : 100 Pieces

nverted energy storage electronic PCB solution to develop power control BMS circuit board custom SMT patch Specification

Thermal Conductivity
Standard FR4 PCB, ~0.25W/mK.

Usage
BMS main board for lithium-ion/lithium iron phosphate battery packs.

Resolution
Voltage/Current detection up to 12-16-bit ADC (based on MCU/IC used).

Input
Voltage/current sense, temperature sensor, communication signals.

Operating Temperature
-20C to +70C (industrial grade components supported).

Display Type
Optional onboard LED status indicators.

Power Source
Battery pack (direct DC input).

Sensors Specification
Temperature sensors: NTC10k/NTC100k, voltage and current measurement inputs.

Features
Custom BMS logic, real-time monitoring, short-circuit/overcurrent protection, temperature protection, data logging.

Response Time
<10ms for protection triggers.

Output
Power relay control, warning/alarm signals, analog/digital communications.

Charging Voltage
Configurable by battery pack, e.g. 14.6V/25.6V/48V.

Interface
UART, CAN, RS485, I2C (customizable communication interface options).

IP Rating
Designed for enclosure mounting, PCB itself is non-rated; up to IP65 with enclosure.

Processor Speed
MCU up to 72MHz (STM32 or similar, optional/custom).

Components
High-precision SMD ICs, MOSFETs, connectors, passive components.

Power Supply
DC input from battery pack (varied, typically 12V/24V/48V).

Product Type
Custom SMT patch PCB for energy storage BMS.

Application
Energy storage solutions, power management, renewable energy battery systems.

Rated Voltage
3.2V~48V (customizable based on battery pack type).

Supply Voltage
12V/24V/48V DC (configurable).

Size
Customizable; sample image shows approx. 120mm x 70mm.

Dimension (L*W*H)
120mm x 70mm x 1.6mm (example, varies as per design).

Function
Energy storage system control, power management, battery monitoring, communication interface.

Color
Green PCB with white silkscreen and black IC chips.

Weight
Approx. 50g ~ 120g (varies with design/customization).

Thickness
1.6mm (PCB standard, can be customized).

Current Rating
Up to 100A (support for higher/lower ratings upon design requirements).

Capacity
Supports 4S-16S lithium cells (configurable).

Frequency
Up to 100kHz PWM for MOSFET switching (depends on IC choice).

Mounting Type
Surface-mount technology (SMT), edge connectors for external interface.

Compliance
RoHS, CE, EMC testing available upon request.

Sampling Rate
100ms typical measurement cycle.

Storage Temperature
-40C to +85C.

Layer Count
2-layer or 4-layer (customization available for higher current demands).

Firmware Upgrade
Supports bootloader for field firmware updates.

Communication Protocols
Modbus, CANopen, custom UART.

PCB Surface Finish
Lead-free HASL/RoHS compliant.

Conformal Coating
Optional for humidity protection.

PCB Material
FR4 high-grade flame retardant.

Customization
Cell count, protection parameters, dimension and shape all fully customizable to client specification.

nverted energy storage electronic PCB solution to develop power control BMS circuit board custom SMT patch Trade Information

Minimum Order Quantity
100 Pieces

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

About nverted energy storage electronic PCB solution to develop power control BMS circuit board custom SMT patch

Discover our top-notch, highly recommended energy storage electronic PCB solution for developing grandiose power control BMS circuit board custom SMT patch-designed with inestimable precision. With a high-grade FR4 flame retardant body, this clearance item is the definitive choice for professionals seeking reliability and adaptability. Layer counts, cell numbers, and parameters are fully customizable, with robust 2/4-layer options for higher current demands. Ending soon-secure advanced features like conformal coating, global communication protocols, RoHS/CE compliance, and superior field firmware upgrades for future-proof deployment. Enhance your energy storage system today!

Versatile Usage & Wide Applications

The nverted energy storage electronic PCB solution is engineered for BMS main board needs in lithium-ion and lithium iron phosphate battery packs. This outstanding SMT patch supports applications in renewable energy systems, power management solutions, and industrial energy storage. Designed for surface-mount technology, the board suits use in commercial energy storage units, solar installations, and smart grid deployments. Its robust and adaptable build ensures suitability for both indoor and enclosed outdoor settings.

Supply, Export & Quotation Details

We offer extensive supply ability as both exporter and manufacturer, ensuring your requirements are efficiently met. Major export destinations include Europe, North America, and Asia, while our domestic market covers all principal Chinese provinces. Each order is carefully packaged for secure shipment, with quotations provided promptly on request. Products are shipped with documentation to assist integration with your operation, maximizing value whether you are a retailer, distributor, or end-user.

FAQ's of nverted energy storage electronic PCB solution to develop power control BMS circuit board custom SMT patch:

Q: How can the BMS circuit board be customized for different applications?

A: The BMS circuit board can be tailored to your needs, adjusting cell count, dimensions, protection parameters, and interfaces. Customization supports different battery pack types and current ratings, ensuring ideal performance in varied applications.

Q: What is the typical usage of this energy storage PCB solution?

A: It is mainly used in lithium-ion and lithium iron phosphate battery management systems, energy storage solutions, renewable energy installations, and industrial power management hardware requiring precise control and monitoring.

Q: Where is this product most commonly applied?

A: Common application places include commercial energy storage units, solar farms, grid-tied battery storage installations, and industrial facilities demanding robust energy management.

Q: When do you recommend using additional features like conformal coating?

A: Adding conformal coating is recommended for installations in environments with high humidity or risk of condensation, to ensure the circuit board remains protected and operational over extended periods.

Q: What are the key benefits of the SMT patch solution?

A: Key benefits include real-time monitoring, customizable protection logic, field firmware upgrades, industry-standard protocol support, and reliable operation in harsh environments-offering peace of mind and improved energy efficiency.
