Name: Internet of things PCB board embedded control board solution
Brand: Shenzhen Dasonghe Trading Co., Ltd.

Get a Price/Quote

MOQ : 100 Pieces

Internet of things PCB board embedded control board solution Specification

Processor Speed
Up to 80 MHz

Display Type
Optional OLED/LCD interface support

Charging Voltage
5V via USB DC input

Resolution
Depends on connected sensors (typically 10-12 bit ADC)

Sensors Specification
Supports DHT, PIR, IR, Gas, and other digital/analog sensors

Output
Digital Output, Communication Interface, Relay Control

Power Supply
DC Input or USB Powered

IP Rating
None (board level only, not waterproof)

Components
Microcontroller, WiFi Module, Connectors, LEDs, Relays, Transistors

Power Source
External DC Supply or USB

Response Time
<1ms (microcontroller processing)

Usage
IoT device development, smart home, automation systems

Input
Digital/Analog Signal Input, Sensor Interface

Features
Low power consumption, onboard WiFi module, multifunctional I/Os, compact design

Interface
GPIO, UART, I2C, SPI

Operating Temperature
-20C to +70C

Thermal Conductivity
Standard FR4 PCB thermal property

Product Type
IoT Embedded Control Board

Application
Internet of Things (IoT), Data Acquisition, Remote Monitoring

Rated Voltage
5V DC

Supply Voltage
3.3V/5V supported

Size
7 cm x 5 cm (approx.)

Dimension (L*W*H)
70 mm x 50 mm x 20 mm

Function
Embedded control and monitoring for Internet of Things (IoT) devices

Color
Green (base PCB), Multicolor (components)

Weight
Approximately 30 grams

Current Rating
Max 2A per output channel

Capacity
Supports multiple sensor and actuator connections

Thickness
1.6 mm PCB thickness

Frequency
Operating Frequency up to 2.4 GHz (WiFi)

Mounting Type
Through Hole and SMD

Firmware Support
Arduino IDE/Third-party SDKs

Relay Specifications
Up to 4 channel relay support (5V control)

Microcontroller Type
ESP8266/ESP32 integrated on board

Indicator Lights
Power, Status, and Data LEDs

Wireless Standard
IEEE 802.11 b/g/n (WiFi)

Protection Features
Reverse polarity and short circuit protection

Storage Temperature
-40C to +85C

Programming Interface
Micro USB/Serial

Compliance
RoHS compliant

PCB Material
FR4 Epoxy Glass

PCB Layer
2-layer design

Connectors
Screw terminals, Dupont headers, USB port

Internet of things PCB board embedded control board solution Trade Information

Minimum Order Quantity
100 Pieces

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

About Internet of things PCB board embedded control board solution

Discover a phenomenal, special offer on our exquisite Internet of Things (IoT) PCB board embedded control solution, featuring a remarked ESP8266/ESP32 microcontroller for superior performance. Take advantage of our reduced price promotion on this robust controller supporting IEEE 802.11 b/g/n WiFi, perfect for seamless IoT integration. Crafted with premium FR4 epoxy glass and advanced protection features, this 2-layer design ensures remarkable durability and reliability. Enjoy versatility with multiple relay channels, sensor support, and easy programming interfaces, making smart automation effortless and innovative for any dealer, service provider, or manufacturer. RoHS compliant.

Extensive Application and Usage Versatility

This embedded IoT PCB board caters to diverse applications-from smart home automation and industrial control, to remote monitoring and data acquisition. Its multifunctional I/Os, sensor interfaces, and wireless connectivity enable both specific and general-purpose uses in IoT device development, smart building projects, and sensor-based automation. Designed for both single projects and scalable system deployment, it meets varied requirements for hobbyists, developers, and system integrators alike, ensuring seamless operation for control and monitoring tasks.

Global Reach: Packaging, Delivery & Export Highlights

Our Internet of Things PCB board is packed with care, ensuring safe dispatch to domestic and international clients. Promptly delivered via our main FOB ports in China, each unit reaches its destination ready for immediate use or seamless exchange if needed. Serving main domestic markets and a wide range of export destinations, we guarantee swift, secure transport for dealers, retailers, and wholesalers. Exceptional packing & dispatch standards uphold quality, supporting customers worldwide in their IoT journey.

FAQ's of Internet of things PCB board embedded control board solution:

Q: How do I program the IoT PCB board with my desired application?

A: You can easily program the IoT PCB board via the Micro USB or serial interface using the Arduino IDE or compatible third-party SDKs, making it adaptable to various custom applications.

Q: What types of sensors and actuators are supported by this embedded control board solution?

A: This board supports multiple digital and analog sensors, including DHT, PIR, IR, and gas sensors, as well as multiple actuators connected through up to 4 relay channels.

Q: Where can this IoT control board be effectively applied?

A: It is ideal for development and integration in smart homes, industrial automation systems, data acquisition platforms, and remote monitoring applications-both general and specialized IoT projects.

Q: What kind of protection features does the control board offer?

A: The board is equipped with reverse polarity and short circuit protection to safeguard connected devices and ensure reliable operation.

Q: When will my order be delivered, and what is the process for exchange if required?

A: All orders are dispatched promptly after packing. Delivery timelines depend on your location and shipping method, with main FOB ports in China. In case an exchange is required, contact our support team to process it efficiently.

Q: What are the main benefits of using this IoT PCB for my projects?

A: Key benefits include onboard WiFi, versatile sensor support, robust protection features, low power consumption, easy mounting, and a compact, RoHS-compliant design ready for global use.
