BMS energy storage power PCBA board foundry material vacuum reflow welding

Send Inquiry

Request To Call Back

BMS energy storage power PCBA board foundry material vacuum reflow welding

Name: BMS energy storage power PCBA board foundry material vacuum reflow welding
Brand: Shenzhen Dasonghe Trading Co., Ltd.

Get a Price/Quote

MOQ : 100 Pieces

BMS energy storage power PCBA board foundry material vacuum reflow welding Specification

Input
Voltage and current from battery pack

Operating Temperature
-40C to +85C

Usage
Energy storage system PCBA for power and battery management

Thermal Conductivity
High efficiency with vacuum reflow welding

Interface
CAN, RS485, UART

Features
Vacuum reflow welding, high reliability, multi-layer PCB, overcharge/discharge/short-circuit/temperature protection, customizable design

Output
BMS data and controlled power output

Power Supply
External DC supply or integrated battery power

Response Time
<100ms system reaction

Charging Voltage
Customized as per battery pack (typically 4.2V/cell for Li-ion)

Components
ICs, MOSFETs, capacitors, resistors, connectors

Power Source
Battery pack/External DC

IP Rating
IP20 (bare PCBA, requires enclosure for higher IP)

Processor Speed
Up to 120MHz for onboard microcontroller

Sensors Specification
Integrated voltage, current, temperature sensors

Product Type
PCBA board for BMS energy storage

Application
Lithium battery packs, energy storage systems, electric vehicles, renewable energy

Rated Voltage
3.7V-1000V (customizable based on application)

Supply Voltage
DC 3.3V/5V (logic), system voltage as per rating

Size
120mm x 78mm

Dimension (L*W*H)
120mm x 78mm x 1.6mm

Function
Battery Management System (BMS) control and protection

Color
Green (PCB color)

Weight
35g

Capacity
Up to 300A (customizable)

Thickness
1.6mm (PCB board thickness)

Current Rating
Up to 300A (depending on system design)

Frequency
50/60Hz system compatible

Conformal Coating
Optional for extra protection

Production Method
OEM/ODM Foundry Service

Packaging
Anti-static vacuum packaging

Mounting Type
SMD and through-hole mixed assembly

MOQ
1 piece for prototyping

Trace Width (Min)
4mil for high current design

Testing
100% functional and ICT test before delivery

Lead Time
7-21 days as per quantity and customization

PCB Layers
4 layers, multi-layer design for high current and stability

Storage Humidity
85% RH

Surface Finish
ENIG (Electroless Nickel Immersion Gold)

Communication Protocols
CAN bus, UART, RS485 supported

ESD Protection
Integrated circuit ESD protection components

Soldering Technology
Vacuum reflow soldering, lead-free process

PCB Material
FR4 high Tg, high reliability

BMS energy storage power PCBA board foundry material vacuum reflow welding Trade Information

Minimum Order Quantity
100 Pieces

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

About BMS energy storage power PCBA board foundry material vacuum reflow welding

Discover our BMS Energy Storage Power PCBA Board, an affordable solution tailored for monumental power management. With a top-notch four-layer multi-layer design, it ensures high current capacity and strong stability. Enjoy the special rate for prototypes (MOQ: 1), with ENIG surface finish and crackerjack vacuum reflow soldering for flawless electrical contact. This board supports essential protocols-CAN bus, UART, and RS485-and offers customizable voltage and capacity. Redeem exceptional value with OEM/ODM foundry material, 100% pre-dispatch testing, and optional conformal coating for superior protection. Ideal for energy storage systems, EVs, and renewables.

Versatile Applications & Surface Excellence

Engineered for lithium battery packs, electric vehicles, and renewable energy systems, this BMS energy storage PCBA board offers robust control in challenging environments. Its green multi-layer surface, enhanced by ENIG finish and vacuum reflow welding, guarantees durability and high performance. Designed for diverse media, it fits seamlessly onto both SMD and through-hole applications. Whether installed in large-scale energy storage plants or compact EVs, the board delivers reliability and efficient power management.

Domestic Market, Streamlined Delivery & FOB Port Services

Serving a wide domestic market across China, our foundry ensures swift transportation and order completion. Delivery times range between 7 and 21 days, depending on order volume and customization. Products are dispatched from major Chinese FOB ports, ensuring reliable international logistics for dealers, exporters, and wholesalers. Customers can track dispatching progress and benefit from anti-static packaging to protect each order during transportation. Experience worry-free purchasing and consistent product quality throughout the supply chain.

FAQ's of BMS energy storage power PCBA board foundry material vacuum reflow welding:

Q: How is the BMS energy storage PCBA board protected against environmental factors?

A: The board features optional conformal coating for additional environmental protection and includes built-in ESD components to safeguard against static discharge during handling and operation.

Q: What application areas are ideal for this PCBA board?

A: This board is optimized for lithium battery packs, large-scale energy storage systems, electric vehicles, and renewable energy infrastructure, serving various sectors requiring dependable battery management.

Q: When can I expect order completion and delivery?

A: Depending on your order quantity and customization needs, your order will be completed and dispatched within 7 to 21 days, with reliable transportation and logistics from China's major FOB ports.

Q: Where does this PCBA board get manufactured?

A: Production is managed by experienced foundry teams in China, following top-notch OEM/ODM processes and stringent quality testing before shipment.

Q: What is the process for ordering prototypes or custom quantities?

A: You can redeem our special rate for prototypes with a minimum order quantity of just one piece, making it easier to test or customize before scaling up bulk orders.

Q: How does the vacuum reflow welding benefit the board's operation?

A: Vacuum reflow welding enhances thermal conductivity and joint integrity, leading to high-efficiency, durable soldering connections that withstand high currents and rigorous use.
