Raspberry Pi industrial board board odm motherboard development SMT patch full process PCB electronic assembly processing

Name: Raspberry Pi industrial board board odm motherboard development SMT patch full process PCB electronic assembly processing
Brand: Shenzhen Dasonghe Trading Co., Ltd.

Get a Price/Quote

MOQ : 100 Pieces

Raspberry Pi industrial board board odm motherboard development SMT patch full process PCB electronic assembly processing Specification

IP Rating
IP00 (bare board)

Interface
USB 2.0, HDMI, Ethernet, GPIO, I2C, SPI

Display Type
HDMI/DSI/optional LCD interface

Usage
ODM/EMS electronic device pilot runs, industrial automation, rapid prototyping

Input
GPIO, USB, Ethernet, HDMI

Sensors Specification
Custom interfaces, supports I2C/SPI sensors

Resolution
1920 x 1080p (HDMI)

Output
GPIO, USB, HDMI, Audio Out, Ethernet

Power Supply
External DC adapter or onboard connector

Processor Speed
1.2 GHz - 1.5 GHz (customizable)

Components
Microprocessor, RAM, Flash, passive SMD/through-hole, connectors, optoelectronics

Charging Voltage
N/A (not battery powered)

Operating Temperature
-20C to +70C

Thermal Conductivity
PCB 0.35-0.50 W/mK

Features
Full-process SMT/PCBA, customizable design, rapid prototyping, RoHS compliant

Response Time
<1ms (digital outputs)

Power Source
DC Adapter, USB micro/Type-C

Product Type
Raspberry Pi industrial development board ODM motherboard

Application
Robotics, industrial control, IoT, education, smart terminals

Rated Voltage
5V DC

Supply Voltage
3.3V/5V (main system rails)

Size
Customizable, standard 85mm x 56mm

Dimension (L*W*H)
85mm x 56mm x 15mm

Function
Industrial embedded computing, PCB processing, custom motherboard development

Color
Green

Weight
55g (typical, varies by configuration)

Capacity
SMT/component population: up to 300 parts/board

Thickness
1.6mm

Current Rating
Max 2.5A/board

Frequency
Up to 1.5GHz (SoC dependent)

Connector Type
Custom, standard pin header, USB, HDMI, RJ45

Testing
AOI, ICT, functional test available

Board Material
FR-4 High TG

PCB Layers
4-layer (standard); up to 8-layer optional

Mounting Type
Surface mount/through hole

SMT Capability
0201 fine pitch, BGA placement up to 0.4mm pitch

Quality Standard
ISO9001/IPC-A-610/ROHS compliant

Production Capacity
5000 boards/month (typical)

Component Packaging
0201, 0402, SOT, TQFP, BGA, QFP supported

Raspberry Pi industrial board board odm motherboard development SMT patch full process PCB electronic assembly processing Trade Information

Minimum Order Quantity
100 Pieces

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

About Raspberry Pi industrial board board odm motherboard development SMT patch full process PCB electronic assembly processing

Experience unparalleled innovation with our exclusive Raspberry Pi Industrial Board ODM motherboard. Now available at a superb Price Cut, this splendid PCB solution enables full SMT patch and assembly processing, supporting up to 8 PCB layers and 300 components per board. Customise every detail-component packaging, connectors, size-tailor-made to your specification. Benefit from incomparably high reliability, ISO9001 and RoHS certification, multi-stage testing, and superior FR-4 material. Perfect for robotics, IoT, education, and industrial automation, this premium board assures you both performance and flexibility, all at an unbeatable value.

Primary Advantages, Industrial Uses & Applications

Our advanced Raspberry Pi industrial motherboard delivers primary competitive advantages including rapid custom designs, quick turnaround, and mass production capacity. Plant applications range from robotics and IoT devices to smart terminals and automation systems. Commercial uses span industrial control panels to education and embedded computing projects. The exclusive full SMT process guarantees excellent reliability and adaptability in challenging environments, ensuring manufacturers and developers achieve efficient, scalable solutions every time.

Certifications, Supply, and Sample Policy

Certified to ISO9001, IPC-A-610, and RoHS standards, this ODM board represents a premium selection for discerning customers. Enjoy transparent list prices and sample policies tailored for pilot runs or commercial scaling. Delivery is punctual, supported by a robust plant with a supply ability of up to 5000 boards each month. The dedicated team ensures every order receives detailed attention, maximizing customer satisfaction and long-term partnership potential.

FAQ's of Raspberry Pi industrial board board odm motherboard development SMT patch full process PCB electronic assembly processing:

Q: How does the SMT full process benefit industrial applications?

A: The full SMT process ensures higher assembly precision, robust component placement (including fine-pitch BGA), and rapid prototyping, making it ideal for stringent industrial applications.

Q: What types of customisation are available with this Raspberry Pi industrial board ODM service?

A: You can personalise board dimensions, select up to 8 PCB layers, specify custom connectors, opt for different packaging types, and choose your preferred mounting method, allowing full control over design.

Q: When can I expect sample delivery for a prototype board?

A: Sample lead time typically ranges from 7 to 14 days after confirming your requirements, subject to complexity and production schedule.

Q: Where are these industrial boards primarily used?

A: Our ODM industrial boards power applications in robotics, industrial automation, IoT systems, smart terminals, and educational prototypes, supporting both development and production runs.

Q: What certifications ensure the quality and reliability of these boards?

A: Every board adheres to ISO9001, IPC-A-610, and RoHS quality standards, ensuring premium performance, environmental compliance, and long-term reliability.

Q: How can I benefit from the Price Cut and exclusive offer?

A: By taking advantage of current Price Cut promotions, you gain access to splendid, feature-rich ODM boards that combine premium quality and superb engineering at a reduced cost-ideal for bulk orders or development trials.
