Raspberry Pi industrial board odm motherboard development SMT patch full process PCB electronic assembly processing

Send Inquiry

Request To Call Back

Raspberry Pi industrial board odm motherboard development SMT patch full process PCB electronic assembly processing

Name: Raspberry Pi industrial board odm motherboard development SMT patch full process PCB electronic assembly processing
Brand: Shenzhen Dasonghe Trading Co., Ltd.

Get a Price/Quote

MOQ : 100 Pieces

Raspberry Pi industrial board odm motherboard development SMT patch full process PCB electronic assembly processing Specification

Operating Temperature
-20C to +70C

Power Supply
USB/External Adapter

Display Type
HDMI/DSI output supported

Thermal Conductivity
Standard PCB with thermal management for surface-mount components

Interface
HDMI, USB 2.0/3.0, Gigabit Ethernet, CSI/DSI, GPIO, UART, I2C, SPI

Usage
Industrial electronics, automation systems, embedded devices

Resolution
Up to 1080p HDMI

IP Rating
Not rated (depends on enclosure, board is open frame)

Components
SMT/Through hole active and passive electronic components, connectors, microprocessor, RAM, storage

Output
HDMI, Audio, USB, Ethernet, GPIO

Processor Speed
Quad-core ARM Cortex-A series, up to 1.5GHz

Features
ODM/OEM customization, SMT patch process, RoHS compliant, high reliability, multi-interface, fast prototyping, robust assembly

Sensors Specification
Support for digital/analog sensors via GPIO/I2C/SPI

Response Time
Instant-On (<1s boot possible with optimized OS)

Power Source
USB, DC Jack, GPIO header

Charging Voltage
5V (if battery backup circuit is used)

Input
HDMI, GPIO, USB, Ethernet, Power

Product Type
Industrial SBC/ODM motherboard

Application
OEM/ODM electronics, industrial control, IoT, prototyping

Rated Voltage
5V DC

Supply Voltage
5V DC

Size
Customizable based on project (standard: 85 x 56 mm)

Dimension (L*W*H)
85mm x 56mm x 15mm

Function
Industrial motherboard development and PCB assembly

Color
Green

Weight
Approx. 45g-80g (depends on configuration)

Thickness
1.6mm PCB

Current Rating
Up to 2.5A (depending on board usage)

Capacity
Depends on selected RAM/Flash (typically 1GB/2GB/4GB RAM)

Frequency
1.2GHz - 1.5GHz (SoC dependent)

Connector Type
Customizable: header, terminal block, socket, pitch available per design

Assembly Process
Full-process SMT PCB assembly including solder paste printing, reflow soldering, AOI/visual inspection, functional testing

PCB Finish
ENIG (Electroless Nickel Immersion Gold)

Testing Methods
ICT (In-Circuit Test), Function Test, AOI

Mounting Type
Surface Mount Technology (SMT), Through-Hole available if required

Number of Layers
4-layer or 6-layer (customizable)

Storage Temperature
-40C to +85C

Compliance
CE/FCC available upon request

PCB Material
FR4, lead-free, RoHS compliant

Production Capacity
Up to 10,000 units/month

Humidity Tolerance
5% - 90% non-condensing

Protection
ESD protection on interfaces, reverse polarity protection on power input

Customizability
ODM/EMS services, hardware/software customization available

Raspberry Pi industrial board odm motherboard development SMT patch full process PCB electronic assembly processing Trade Information

Minimum Order Quantity
100 Pieces

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

About Raspberry Pi industrial board odm motherboard development SMT patch full process PCB electronic assembly processing

Order world-class Raspberry Pi industrial boards with opulent features, masterful design, and competitive pricing. Our custom ODM motherboard development includes full-process PCB electronic assembly, using high-quality FR4, lead-free, RoHS-compliant materials. Choose from 4-layer or 6-layer SMT patch technology with through-hole options. Enjoy a special rate for bulk production (up to 10,000 units/month) with ESD/reverse polarity protection, CE/FCC compliance, and ENIG finish. Precision testing (AOI, ICT, function testing) ensures reliability-perfect for industrial electronics, automation, IoT, or custom prototyping.

Application Areas & Advanced Features

Ideal for OEM/ODM electronics, industrial control, IoT, prototyping, and embedded devices, this Raspberry Pi industrial board offers masterful flexibility and robust assembly. Advanced features include multi-interface I/O (HDMI, USB, GPIO, Ethernet), support for high-resolution displays, rapid response time, and extensive connector/customization options. Its thermal management, 4-6 layer FR4 PCB, and comprehensive protection ensure reliability in demanding automation and electronic systems, meeting the needs of world-class, high-performance industrial applications.

Certifications, Packaging & Domestic Market Dissemination

All boards can be supplied with CE and FCC certifications based on order requests. Experience seamless drop-off, quick dispatch, and efficient handover through our well-established domestic distribution network. Packaging is engineered for top-tier protection, ensuring safe transit and rapid delivery. We take pride in transparent logistics and timely shipments across principal markets, supporting dealers, distributors, exporters, and service providers with reliable, on-time fulfillment from our manufacturing base in China.

FAQ's of Raspberry Pi industrial board odm motherboard development SMT patch full process PCB electronic assembly processing:

Q: How is the assembly process managed for Raspberry Pi industrial boards?

A: The assembly process includes full-process SMT PCB assembly: solder paste printing, reflow soldering, AOI and visual inspection, in-circuit and functional testing, ensuring rigorous quality control at every stage.

Q: What customization options are available for these motherboards?

A: We offer ODM/EMS services with customizable layers, PCB dimensions, connectors, interfaces, hardware, and software according to your specific project requirements.

Q: Where can these industrial boards be deployed for maximum efficiency?

A: They are ideal for industrial automation, control systems, IoT deployments, embedded devices, prototyping, and large-scale OEM/ODM electronics projects requiring reliability and flexibility.

Q: When can I expect quick dispatch and delivery after placing my order?

A: Thanks to our efficient production and logistics chain, most standard orders are ready for drop-off and handover within a short turnaround-subject to order size and customization.

Q: What are the main benefits of choosing your PCB assembly services?

A: You benefit from competitive pricing, world-class manufacturing standards, comprehensive testing, high reliability, flexible customization, and on-demand CE/FCC certification for global compliance.

Q: How is the Raspberry Pi industrial board protected during operation?

A: Boards come with ESD protection on interfaces and reverse polarity protection for power inputs, ensuring safe operation in various industrial environments.
