Custom pressure control ventilator control board PCBA program board development

Name: Custom pressure control ventilator control board PCBA program board development
Brand: Shenzhen Dasonghe Trading Co., Ltd.

Get a Price/Quote

MOQ : 100 Pieces

Custom pressure control ventilator control board PCBA program board development Specification

Operating Temperature
0C to 50C

Features
Custom firmware, overvoltage protection, anti-static design, modular connectors

Output
Actuator/valve drive, digital display output

Response Time
<5 ms

Display Type
Digital segment LED

Resolution
0.1 hPa

Components
Microcontroller, MOSFET drivers, pressure sensor interface, capacitors, resistors

Sensors Specification
Compatible with analog and digital pressure sensors

Usage
Medical ventilators, respiratory equipment

Input
Pressure sensor input, digital controls

Thermal Conductivity
Standard FR4 ~0.25 W/mK

Power Source
External DC

Power Supply
External DC adapter

IP Rating
IP20

Processor Speed
16 MHz

Interface
UART, I2C, GPIO headers

Product Type
Pressure control ventilator control board PCBA

Application
Medical device control circuits

Rated Voltage
12V DC

Supply Voltage
10-15V DC

Size
90 mm x 60 mm

Dimension (L*W*H)
90 mm x 60 mm x 20 mm

Function
Precise pressure control and real-time monitoring for ventilator systems

Color
Green

Weight
185 g

Thickness
1.6 mm

Current Rating
Max 2A

Capacity
Handles pressure signals up to 1000 hPa

Frequency
Operating up to 100 kHz internal clock

PCB Material
High-grade FR4 with lead-free HASL finish

Firmware Upgradeability
On-board micro USB port

Connector Type
2.54mm header pins

Compliance
RoHS, CE Marked

Life Cycle
Designed for 5+ years of continuous operation

Humidity Range
10% ~ 90% RH non-condensing

PCB Surface Finish
HASL Lead-Free

Board Layer
2 Layer

Insulation Voltage
500V

Reverse Polarity Protection
Integrated diode protection

Programming Interface
External ISP/JTAG support

Mounting Type
Hole and edge connector mounting

Custom pressure control ventilator control board PCBA program board development Trade Information

Minimum Order Quantity
100 Pieces

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

About Custom pressure control ventilator control board PCBA program board development

Experience the elite standard in medical device engineering with our featured Custom Pressure Control Ventilator Control Board PCBA. Built from high-grade FR4 and finished with a grand, lead-free HASL surface, it redeems exceptional durability and supreme reliability. Designed for precise, real-time pressure control, it integrates advanced microcontrollers, MOSFET drivers, and digital interfaces for the finest operational excellence. RoHS and CE marked, the board boasts elite insulation, modular connectors, and reverse polarity protection, ensuring both performance and safety for ventilator and critical respiratory applications worldwide.

Prime Applications and Premium Features

Suitable for medical ventilators and respiratory devices, this control board is engineered for the demanding environments of healthcare plants and facilities. The board's extra features include custom firmware, integrated overvoltage and anti-static protection, modular connectors, and support for both analog and digital sensor interfaces. With a grand design optimized for long-term operation and dealer, distributor, importer, or manufacturer use, its exceptional reliability makes it ideal for medical device control circuits.

Sample Policy and Reliable Supply Logistics

Samples of our custom PCBA control board are available on request, with a clear sample policy to facilitate evaluation. We ensure secure goods transport, with each board professionally packed and shipped worldwide. Our handover process prioritizes quick turnaround and safe delivery. With robust supply ability, we meet the needs of exporters, fabricators, and wholesale distributors, ensuring a smooth and consistent shipping experience for every customer.

FAQ's of Custom pressure control ventilator control board PCBA program board development:

Q: How does the ventilator control board ensure precise pressure regulation?

A: The board utilizes high-resolution pressure input, fast response (<5 ms), and real-time digital monitoring to control actuators or valves with exceptional precision, supporting both analog and digital pressure sensors.

Q: What programming interfaces are available for firmware development?

A: External ISP and JTAG support are provided for programming, along with a micro USB port enabling effortless on-board firmware upgrades to enhance or redeem control functions as needed.

Q: When can users expect the handover of their order after purchase?

A: Orders are typically processed and shipped within standard industry timelines, with expedited goods transport and prompt handover, ensuring fast and reliable reception for urgent medical applications.

Q: Where can this PCBA control board be used?

A: The board is ideal for medical ventilators, respiratory equipment, and integrated plant control systems in healthcare facilities requiring superior pressure monitoring and automation.

Q: What are the main benefits of using this elite control board?

A: It offers long-term reliability (5+ years), robust safety with reverse polarity and overvoltage protection, modular expansion, precise monitoring, compliance with international standards, and exceptional adaptability for diverse medical control needs.
